Our PCB Manufacturing & Assembly Services
A wide range of PCB manufacturing and assembly services to meet your prototype and small-series requirements, all produced and assembled in our own facilities in Germany and Hungary.
Fast & easy online ordering and multilingual sales & customer support available via online chat, telephone, or email.
- PCB Manufacturing
- PCB Assembly
PCB proto
PCB Proto service offers customers a simple and no fuss fast Prototyping service.
- Std Delivery – 3 WD for Bare Boards or 6 WD Assembled
- 2 or 4 Layers
- Leads free finish included
STANDARD pool
STANDARD pool PCB manufacturing service covers most of your needs for standard PCB production.
- Std Delivery – 5 WD for Bare Boards or 10 WD Assembled
- Up to 16 Layers
- 100µm Track & Gap pooling – 90 µm Non-pooling
HDI pool
HDI Pool service enables designers to integrate microvias into their layouts for fine-pitch components and .benefit from the cost advantages of pooling.
- Std Delivery – 12 WD for Bare Boards or 17 WD Assembled
- 100µm microvias
- 8 Layers
Defined Impedance pool
- Std Delivery – 5 WD for Bare Boards or 10 WD Assembled
- Characteristic and Differential Impedance PCBs
- 4, 6 and 8 Layers
- 100µm Track & Gap pooling – 90µm Non-pooling
RF pool
- Std Delivery – 5 WD for Bare Boards or 10 WD Assembled
- Isola I-TERA and Rogers 4000 series material
- 2 & 4 Layers
- 100µm Track & Gap pooling – 90 µm Non-pooling
SEMI-FLEX pool
A flex to install solution
- Std Delivery – 7 WD for Bare Boards or 12 WD Assembled
- 4 layer
- 100 micron FR4 core with two specially treated copper layers
IMS pool
- Std Delivery – 5 WD for Bare Boards or 10 WD Assembled
- Single layer Insulated Metal Substrate PCBs (ALU)
eC-stencil
- Stainless Steel Laser Cut Stencils for Solderpaste
- Stencil thickness – 100µm or 130µm
Assembly capabilities
- Std Delivery from 3 days (plus PCB Manufacture lead time)
- BGA with 0,4mm pitch and above
- Single and Double side assembly of SMT & THT technology
Generic components
- Generic Capacitor, Resistors and Pin Headers available from stock
- Many available free of charge
- All stock components held by Eurocircuits are RoHS compliant
